Single or Three Phase Automatic Transformer Turns Ratio Meter TTR Meter

Single or Three Phase Automatic Transformer Turns Ratio Meter TTR Meter

    • Single or Three Phase Automatic Transformer Turns Ratio Meter TTR Meter
    • Single or Three Phase Automatic Transformer Turns Ratio Meter TTR Meter
    • Single or Three Phase Automatic Transformer Turns Ratio Meter TTR Meter

    Detalhes do produto:

    Lugar de origem: CHINA
    Marca: AI
    Certificação: ISO
    Número do modelo: TTR

    Condições de Pagamento e Envio:

    Quantidade de ordem mínima: 1 conjunto
    Preço: Negociável
    Detalhes da embalagem: Caixa de madeira compensada
    Tempo de entrega: 15 dias
    Termos de pagamento: T/T, Western Union, L/C
    Habilidade da fonte: 100000 conjuntos por mês
    contacto
    Descrição de produto detalhada
    Fonte de energia: AC220V±10%, 50Hz/60Hz Mostrar: LCD
    Faixa de medição: 1-10000 Grupo de medição: 1-12
    Garantia: 1 ano palavra-chave: Medidor de relação de voltas do transformador, medidor TTR



    Single Three Phase Transformer Turns Ratio Tester TTR Meter

    Single or Three Phase Automatic Transformer Turns Ratio Meter TTR Meter

    I. Introduction:

    • This transformer turns ratio tester can test voltage ratio for three or singe phase transformer

    • The group vector measurement for three phase transformer.

    • The polarity measurement for single phase transformer or CT/PT

    • Voltage ratio error calculation

    • Current transformer ratio measurement

    • Excitation current measurement in ratio testing

    • Reproduction the AC test voltage from power source to reduce the effects of bad power source

    • Save the test results in the memory internal the TTR meter

    • This turns ratio meter can print the test results by micro build-in printer

    • Reverse connection detect unit to prevent the high voltage injected to operator

    • Over current protection unit integrated in software and hardware

    • Upload the test results to PC by RS232 and make word report by software



    II. Specifications:

    1 Product Name Single and Three Phase Transformer Turns Ratio TTR Tester
    2 Ratio measurement range 1-10000
    3 Group measurement 1-12
    4 Phase measurement error 1 degree
    5 Ratio measurement error 1-2000 ± 0.2%RDG 2000-10000 ± 0.5%RDG
    6 Test voltage 0~80V, frequency 50Hz
    7 Power supply AC220V ± 10%, 50Hz/60Hz
    8 Environment temperature 0-50°C
    9 Humidity ≤85%R
    10 Dimension 58*45*36CM
    11 Weight 22Kg






    Spare Package of Single or Three Phase Automatic Transformer Turns Ratio Meter TTR Meter

    Single or Three Phase Automatic Transformer Turns Ratio Meter TTR Meter
