Loop Resistance Instrument Contact Resistance Test Equipment 100A 200A 400A 600A

Loop Resistance Instrument Contact Resistance Test Equipment 100A 200A 400A 600A

    • Loop Resistance Instrument Contact Resistance Test Equipment 100A 200A 400A 600A
    • Loop Resistance Instrument Contact Resistance Test Equipment 100A 200A 400A 600A
    • Loop Resistance Instrument Contact Resistance Test Equipment 100A 200A 400A 600A

    Detalhes do produto:

    Lugar de origem: CHINA
    Marca: AI
    Certificação: ISO
    Número do modelo: CRT

    Condições de Pagamento e Envio:

    Quantidade de ordem mínima: 1 conjunto
    Preço: Negociável
    Detalhes da embalagem: Caixa de madeira compensada
    Tempo de entrega: 15 dias
    Termos de pagamento: T/T, Western Union, L/C
    Habilidade da fonte: 100000 conjuntos por mês
    contacto
    Descrição de produto detalhada
    Fonte de energia: AC220V±10%, 50Hz/60Hz Mostrar: LCD
    Faixa de medição: 0-1999,9 μΩ Corrente de medição: CC 100A, 200A, 400A, 600A
    Garantia: 1 ano palavra-chave: Instrumento de resistência de loop, testador de resistência de contato





    100A 200A 400A 600A Low Contact Loop Resistance Tester





    Introduction:

    • Contact resistance tester is used to test the contact resistance of circuit breaker or high current cable contacts.

    • It is designed according to IEC62271.

    • The main application of the tester is measurement of circuit breaker contact resistance.

    • All the test results of loop resistance tester could be print by the micro-printer which is integrated in the tester.

    • Also all the test results saved in the low resistance meter could be uploaded to PC computer and then convert to MS WORD document.



    Features:

    • Rapid test;

    • Result print;

    • Upload data to PC;



    Specifications:

    1 Measuring range 0-1999.9 μΩ Resolution:0.1 μΩ
    2 Measuring current DC 100A, 200A, 400A, 600A for choice
    3 Measuring precision 0.5 %RGD+0.05%FS
    4 Display mode LCD
    5 Data storage Save no more than 100 groups of data
    6 Data connection RS232 computer interface
    7 Rated power supply AC220V
    8 Size 340mm× 280mm × 210mm
    9 Environment temperature -10 ℃~+40 ℃
    10 Relative humidity <80%






    Picture of 400A Low Contact Loop Resistance Tester

    Loop Resistance Instrument Contact Resistance Test Equipment 100A 200A 400A 600A
