30KV Insulating Boots and Gloves Withstand Voltage Test Bench For 3 Pairs

30KV Insulating Boots and Gloves Withstand Voltage Test Bench For 3 Pairs

    • 30KV Insulating Boots and Gloves Withstand Voltage Test Bench For 3 Pairs
    • 30KV Insulating Boots and Gloves Withstand Voltage Test Bench For 3 Pairs
    • 30KV Insulating Boots and Gloves Withstand Voltage Test Bench For 3 Pairs
    • 30KV Insulating Boots and Gloves Withstand Voltage Test Bench For 3 Pairs
    • 30KV Insulating Boots and Gloves Withstand Voltage Test Bench For 3 Pairs

    Detalhes do produto:

    Lugar de origem: CHINA
    Marca: AI
    Certificação: ISO
    Número do modelo: IGB

    Condições de Pagamento e Envio:

    Quantidade de ordem mínima: 1 conjunto
    Preço: Negociável
    Detalhes da embalagem: Caixa de madeira compensada
    Tempo de entrega: 15 dias
    Termos de pagamento: T/T, Western Union, L/C
    Habilidade da fonte: 100 conjuntos por mês
    contacto
    Descrição de produto detalhada
    Fonte de energia: 0-220 V, 50 Hz Mostrar: Digital
    Faixa de medição: 0~30KV Capacidade: 3KVA
    unidades de teste: 6 pcs Garantia: 1 ano

    Insulating Boots and Gloves Withstand Voltage Test Bench

    I. Introduction:

    This insulating gloves and boots test bench is used to test leakage current,insulation aging,power frequency of insulating gloves and boots.It can test 3 pairs for each time and to read leakage current of each pair in order to find which one is unqualified.There are trundles in the bottom which make more convenience for moving.





    II.Main Features

    1. Input voltage:AC220V 50Hz
    2. Output voltage:0~30KV
    3. Capacity:3kVA
    4. Test units:6 units each time
    5. Test data:Display and print voltage data and leakage current data of each unit
    6. Overcurrent protection:Overvoltage protection；User-defined time setting,display voltage data and leakage current data
    7. Accuracy:Voltage ±2%(±3 digits) Current±2%(±3 digits)
    8. Weight:control unit 12kg; test bench 60kg







    III. Package List

    1 Test car 1 Set
    2 Test bench 1 Set
    3 HV test transformer 1 Set
    4 Test cable 1 Set
    5 Manual book 1 Copy



    Photo of Insulating Boots and Gloves Withstand Voltage Test Bench30KV Insulating Boots and Gloves Withstand Voltage Test Bench For 3 Pairs30KV Insulating Boots and Gloves Withstand Voltage Test Bench For 3 Pairs
