VTD Double Stage High Vacuum Oil Filtration Plant for Transformer Oil

VTD Double Stage High Vacuum Oil Filtration Plant for Transformer Oil

VTD Double Stage High Vacuum Oil Filtration Plant for Transformer Oil

Detalhes do produto:

Lugar de origem: CHINA
Marca: AI
Certificação: ISO
Número do modelo: VTD

Condições de Pagamento e Envio:

Quantidade de ordem mínima: 1 conjunto
Preço: Negociável
Detalhes da embalagem: Estojo de madeira
Tempo de entrega: 30 dias
Termos de pagamento: D/P, T/T, Western Union
Habilidade da fonte: 100 conjuntos por mês
contacto
Descrição de produto detalhada
Função: filtragem de óleo de transformador usado Capacidade nominal: 1800L/H-18000L/H
Vazio de trabalho: -0,06~0,099MPa Fonte de energia: 50 Hz, 380 V, 3 fases 4 fios
Potência total: 52KW Operação barulhenta: ≤80db (a)
Cor: Azul ou personalizado Garantia: 1 ano

VTD Double Stage High Vacuum Oil Filtration Plant

​I.Application:

This transformer oil filtration plant is mainly used to remove gas,water and impurities in insulation oil and improve transformer oil's dielectric strength.It can also be used for pumping vacuum for transformer,vacuum oil injection and thermal oil circulation.



II.Technical specifications

  • Model:VTD Transformer oil filtration plant
  • Nominal capacity:4000L/h or other flow rate
  • Working vacuity:-0.06～0.099 MPa
  • Limit vacuity:≤5-8Pa
  • Working oil temperature:45～65℃
  • Working pressure:≤0.5Mpa
  • Power supply:50Hz,380V,3 phase 4 wire
  • Heating power:48Kw
  • Total power:52kw
  • Head:≥15m
  • Operation noisy:≤80dB(A)
  • Diameter of oil inlet/outlet:42/42mm
  • Continuous operation time:≥200 hours
  • Average faultless working time:≥5000 hours



III.Index of clean transformer oil

1 Water content ≤10ppm
2 Gas content ≤0.5%(by volume)
3 Filter accuracy ≤1µm
4 Breakdown voltage ≥70KV(Ball)
5 Ethane content Null





IV.Optation Parts for transformer oil purifier

1.Aluminum case

2.Online water detector(Viasala)
