ENV 1187 Fire Performance Test Equipment for External Fire Exposure to Roofs

Product Introduction

The Roofing Fire Performance Test Equipment with Burning Brands for fire reactivity of roofing materials is developed according to GB/T 30735-2014 "Test Methods for External Fire Reaction of Roofs and Roof Covering Products". The test method mainly refers to the t1 test method in ENV 1187 and ISO 12468-1. This method specifies three test methods under fire conditions. Method A corresponds to t1 in ENV 1187, and Method B and Method C correspond to ISO 12468-1. Respectively simulate the state of the external reaction of the roof and roof covering products to fire under the adjustment of wind and heat radiation.

Performance characteristics

1. The test sample frame structure is made of metal square pipe welding and angle steel;

2. The test angle of the test sample holder can be adjusted, and the pneumatic adjustment method is adopted. The user only needs to operate by the button, which is convenient for the user to use;

3. The adjustable range of the test stand angle is 0-50 degrees, which meets the test requirements of ISO 12468 Method A and ENV 1187 t1 for the maximum inclination height of the sample to be 45 degrees;

4. The air duct material is SUS304 stainless steel with a thickness of 2 mm. A fine honeycomb grille is installed in the upper air duct and a coarse honeycomb grille at the outlet;

5. The fan specifications are: the maximum fan speed is 250 cubic meters/min, and the fan motor power is 5.5KW;

6. Fan frequency conversion adjustment device: 3-phase 380V power 5.5KW;

7. The air duct adopts ball screw and servo motor drive mode, which can automatically adjust the angle;

8. The adjustable angle range of the air duct is 0-35 degrees, which meets method B and method C in ISO 12468;

9. The Roofing Fire Performance Test Equipment is equipped with 3 impeller anemometers with an accuracy of 0.1m/s;

10. The size of the radiating surface of the radiator is 600mmx600mm;

11. Roofing Fire Test with Burning Brands provides a small stainless steel tube burner, which can be used for wood shavings burning test;

12. 1 set of wood stack fire gas burning device;

13. Roofing Fire Performance Test Equipment provides 2 sets of video monitoring devices;

14. Roofing Fire Performance Test Equipment is equipped with computer and printer device and standard test software.
