Petroleum Oils Solidifying Point&Cold Filter Plugging Point Testing Equipment

Petroleum Oils Solidifying Point&Cold Filter Plugging Point Testing Equipment

    • Petroleum Oils Solidifying Point&Cold Filter Plugging Point Testing Equipment
    • Petroleum Oils Solidifying Point&Cold Filter Plugging Point Testing Equipment
    • Petroleum Oils Solidifying Point&Cold Filter Plugging Point Testing Equipment

    Detalhes do produto:

    Lugar de origem: CHINA
    Marca: AI
    Certificação: ISO
    Número do modelo: SPT-I

    Condições de Pagamento e Envio:

    Quantidade de ordem mínima: 1 conjunto
    Preço: Negociável
    Detalhes da embalagem: Cartão duro
    Tempo de entrega: 20 dias
    Termos de pagamento: L/C, T/T, Western Union
    Habilidade da fonte: 20 séries por mês
    contacto
    Descrição de produto detalhada
    Padrões: GB/T510 Aplicativo: Testando Ponto de Solidificação e CFPP
    Consumo de energia: 1000kW Garantia: 1 ano
    Tamanho: 620 mm × 460 mm × 355 mm Fonte de energia: CA （220±10%）, 50Hz
    Câmara de trabalho: Dois Faixa de temperatura: Ambiente até -70℃

    Petroleum Oils Solidifying Point&Cold Filter Plugging Point Testing Equipment


    Summary
    This instrument is newly designed and made as per national standard of People's Republic of China GB/T510 Standard Test Method for Solidifying Point of Petroleum Oils.It is suitable to determine solidifying point of petroleum products. It is widely used in oil exploitation companies, petroleum manufacturers, petroleum users, colleges and scientific research institutes.

    I. Main technical features
    1. The material of workbench is stainless steel. It has two cooling baths in one chamber. The two cooling baths are the same in temperature.
    2. It adopts special technology. It is no need to use cooling liquid in cold chamber. The cooling rate is fast and efficiency is high. The temperature in cooling baths is uniform and it can reach -70℃. The precision is ±0.5℃.
    3. The instrument adopts bench structure. The design is simple and easy to use. Operator can do solidifying point test as long as buying this equipment.

    II. Main technical specifications
    1. Power supply: AC(220±10%), 50Hz
    2. Working chamber: Two test baths in one chamber. The temperatures are the same.
    3. Temperature range: Ambient to -70℃
    4. Temperature control accuracy: ±0.5℃
    5. Refrigeration: New-type refrigeration compressor
    6. Ambient temperature: ≤30℃
    7. Relative humidity: ≤85%
    8. Maximum power consumption: 1000W
    9. Dimension: 620mm×460mm×355mm


    III.SPT-I Solidifying Point Testing Eequipment Accessories and Documents List

    No. Name Unit Qty Memo
    1 SPT-I Solidifying Point Testing Equipment Set 1
    2 Thermometer(-80～60)℃ scale mark 1℃ Piece 1
    3 Stopping ring of thermometer(1#) Piece 2
    4 Fuse 10A(Ф5×20) Piece 2
    5 Bath cover Piece 2
    6 Operation manual Piece 1
    7 Temperature control device usage manual Piece 1





    IV,SPT-I Solidifying Point Tester's Reagent and Auxiliary Equipments

    No. Name Specification Quantity Memo
    1 Absolute ethyl alcohol Analytical pure 500ml 3 bottles
