ASTM D2420 LPG Hydrogen Sulfide Tester for Liquefied Petroleum Gas

ASTM D2420 LPG Hydrogen Sulfide Tester for Liquefied Petroleum Gas

    • ASTM D2420 LPG Hydrogen Sulfide Tester for Liquefied Petroleum Gas
    • ASTM D2420 LPG Hydrogen Sulfide Tester for Liquefied Petroleum Gas
    • ASTM D2420 LPG Hydrogen Sulfide Tester for Liquefied Petroleum Gas
  • ASTM D2420 LPG Hydrogen Sulfide Tester for Liquefied Petroleum Gas

    Detalhes do produto:

    Lugar de origem: CHINA
    Marca: AI
    Certificação: ISO
    Número do modelo: AIC-2420

    Condições de Pagamento e Envio:

    Quantidade de ordem mínima: 1 conjunto
    Preço: Negociável
    Detalhes da embalagem: Caixa de madeira compensada
    Tempo de entrega: 20 dias
    Termos de pagamento: Western Union, T/T, L/C
    Habilidade da fonte: 20 séries por mês
    contacto
    Descrição de produto detalhada
    Padrão de teste: ASTM D2420, SH/T0125 Modo de regulação da temperatura: Termostato digital PID
    Potência total: 1000W Dimensão: 440*310*600mm
    Fonte de energia: AC220V 50Hz Garantia: 1 ano
    Cor: Branco Peso: 20kg

    ASTM D2420 LPG Hydrogen Sulfide Tester

    Introduction
    This instrument is used to detect the presence or absence of hydrogen sulfide in liquefied petroleum gas. The lower limit of detection of hydrogen sulfide is 4mg/m3.If methyl mercaptan is present on the lead acetate test strip, it will produce a short-term yellow stain, but it will disappear completely in less than 5 minutes.Other sulfides in liquefied petroleum gas do not interfere with this test.

    I. Main features
    ◆The test glass tube meets the requirements of the standard, with a glass hook inside.
    ◆Provide 500ml stainless steel sampler.
    ◆The gas passes through the thermal evaporation bath and the needle valve adjusts the flow.
    ◆Imported Omron PID temperature controller, digital continuous display temperature, accuracy 0.1℃.



    II.Technical specifications
    Applicable Standard
    ASTM D2420, SH/T0125
    Heating mode
    Electric heating tube
    Temperature controlling mode
    Digital PID thermostat
    Flow control
    Needle valve adjustment, flow meter displays flow
    Power supply
    AC220V/ 50HZ
    Total power
    1000W
    Dimension
    440*310*600mm
    Weight
    20KG



    III.Pacakge list
    No.
    Name
    Quantity
    Unit
    1
    Main unit
    1 Set
    2
    Fuse 20A
    4
    PC
    3
    Sampling cylinder 500ml
    1
    PC
    4
    Glass hook
    1
    PC
    5
    Fuse 20A
    4
    PC
    6
    Rubber stopper 10#
    1
    PC
    7
    Glass cylinder
    1
    Set
    8
    Watch glass
    1
    PC
    9
    Glass connecting pipe
    1
    Root
    10
    Breathing pipe
    1
    PC
    11
    Test strip
    1
    Box
    12
    User manual
    1
    Copy
    ASTM D2420 LPG Hydrogen Sulfide Tester for Liquefied Petroleum Gas
