| Lugar de origem: | CHINA |
| Marca: | AI |
| Certificação: | ISO |
| Número do modelo: | AIC-1743 |
| Quantidade de ordem mínima: | 1 conjunto |
|---|---|
| Preço: | Negociável |
| Detalhes da embalagem: | Testador de propriedades preventivas de corrosão embalado em caixa de madeira compensada |
| Tempo de entrega: | 20 dias |
| Termos de pagamento: | Western Union, T/T, L/C |
| Habilidade da fonte: | 20 séries por mês |
| Padrão de teste: | GB/T5018, ASTM D1743 | Modo de aquecimento: | Banho de metal |
|---|---|---|---|
| Modo de temporização e intervalo: | Temporizador digital, 0,01s ~ 99h99m | Velocidade do motor: | 1450r/min |
| Fonte de energia: | CA 220 V, 50 Hz | Garantia: | 1 ano |
| Cor: | Prata | Peso: | 18 kg |
| Escala de controlo da temperatura: | ambiente~150℃±0,1℃ |
Coat the sample on a new bearing and run it for 60 seconds under a light thrust load to distribute the grease as it is used. The bearing is stored for 48 hours at 52 degrees and 100% relative humidity, and then clean and inspect for signs of corrosion on the outer ring raceway of the bearing.
Main feature
◆The Corrosion Preventive Properties Tester is equipped with a set of mechanical greasers and a set of thrust loader;
◆Automatically control the running time, and automatically shut down when the test requirements are reached;
◆Bearing meets standard requirements;
◆Digital display of working hours.
Technical specifications
| Model | AIC-1743 |
| Applicable standard | GB/T5018,ASTM D1743 |
| Motor speed | 1450r/min |
| Power supply | AC220V 50HZ |
| Total power | 800W |
| Dimension | 360*480*550mm |
| Weight | 18KG |
Accessories List
| No. | Name | Specification | Quantity |
| 1 | Corrosion Preventive Properties Tester | 1 Set | |
| 2 | Shaft loading accessories | 1 Set | |
| 3 | Mechanical greaser | 1 Set | |
| 4 | Pliers | 1 PC | |
| 5 | Standard bearing | 1 PC | |
| 6 | Fuse | 20(A) | 4 PCS |
| 7 | Injector | 100ml | 1 PC |
| 8 | Silicon tube | Φ4 | 1 Root |
| 9 | Manual book | 1 Copy |
![]()
