IP 278 Seal Compatibility Index Test Equipment for Petroleum Oils

IP 278 Seal Compatibility Index Test Equipment for Petroleum Oils

    • IP 278 Seal Compatibility Index Test Equipment for Petroleum Oils
    • IP 278 Seal Compatibility Index Test Equipment for Petroleum Oils
    • IP 278 Seal Compatibility Index Test Equipment for Petroleum Oils
    • IP 278 Seal Compatibility Index Test Equipment for Petroleum Oils

    Detalhes do produto:

    Lugar de origem: CHINA
    Marca: AI
    Certificação: ISO
    Número do modelo: AIC-278

    Condições de Pagamento e Envio:

    Quantidade de ordem mínima: 1 conjunto
    Preço: Negociável
    Detalhes da embalagem: Cartão duro
    Tempo de entrega: 30 dias
    Termos de pagamento: L/C, T/T, Western Union
    Habilidade da fonte: 20 séries por mês
    contacto
    Descrição de produto detalhada
    Fonte de energia: AC220V /50Hz Método de aquecimento: Tubos de aquecimento elétrico de aço inoxidável
    Padrão de teste: IP278 Método de controle de temperatura: Omron
    Faixa de controle de temperatura: TA~100 ºC Dimensão: 600*600*650mm3
    Tensão de trabalho: 10KV±2% Peso: 40kg
    Potência total: 1200W Serviço OEM: Disponível

    Summary
    This Seal Compatibility Index Test Equipment is suitable for the determination of various petroleum products, but it is not suitable for the determination of water containing petroleum products.
    Measure the inner diameter of the rubber ring with a conical gauge, then soak the rubber ring in the sample at a certain temperature for 24 hours, take it out for cooling, and measure the change of the rubber inner diameter with a conical gauge.

    I. Main technical features
    1.The air guide cooling system automatically starts to dissipate heat when the surface temperature of the instrument is too high;
    2.The     Seal Compatibility Index Test Equipment adopts Novel V-shaped door opening mode, fully transparent high-temperature resistant glass door;
    3.Enamel liner is corrosion-resistant and easy to clean;
    4.The box is equipped with fan circulation and lighting devices;
    5.Standard alloy steel gauge is provided with this Seal Compatibility Index Tester;
    6.Imported Omron PID temperature controller, digital display temperature, accuracy 0.1 ºC
    7.Working range: room temperature ~ 100 ° C ± 1 ° C;
    8.The     Seal Compatibility Index Test Equipment has over temperature safety protection.

    II. Main technical specifications
    1 Applicable standard SH/T 0305,IP 278
    2 Heating method Stainless steel electrical heating tube
    3 Temperature control method Imported PID temperature controller
    4 Temperature control range RT~100 ºC
    5 Temperature control accuracy ±1 ºC
    6 Working voltage 10KV±2%
    7 Dimension 600*600*650mm3
    8 Weight 40KG
    9 Total power 1200W
    10 Power supply AC 220V±10%, 50 Hz



    IP 278 Seal Compatibility Index Test Equipment for Petroleum Oils
